How to charge IRD202 Vibration Meter and Bearing Health Checker

How to charge IRD202 Vibration Meter and Bearing Health Checker

IRD202 Vibration Meter and Bearing Health Checker runs on an internal 4000 mAh Lithium Polymer (LiPo) rechargeable battery. It does not use AA batteries, and the battery does not need to be removed for charging.

How to charge

  1. Connect a USB-C cable to the USB-C port on top of the meter.
  2. Use a 5 V DC, 0.5 A charger (recommended): 0 to full in about 8 hours.
  3. A 5 V DC, 3 A charger fast-charges in about 1 hour, but fast charging affects battery health — prefer normal charging most of the time.
The same USB-C port is used for data transfer to the IRD202 Data Explorer PC software.
See the full IRD202 User Manual.
